DEH-80PRS/XNUC

5 678

7. DISASSEMBLY

While the photograph shown is slightly different from this model in shape, the disassembly procedure is the same.

Push the area and remove the two hooks.

Slide the Tuner Amp Assy in the direction

of the arrow.

Disconnect the FFC and then remove the

CD Mechanism Module.

2 2

Lift off the Tuner Amp Assy from the Front Side.

Front

Heat Sink Side

The CD Mechanism Module side is made a bottom.

- Removing the CD Mechanism Module (Fig.2, 3, 4)

CD Mechanism Module

Tuner Amp Assy

Remove the two screws.

Release the two latches and then remove

the Panel Assy.

- Removing the Panel Assy (Fig.1)

Fig.4

Fig.1

Fig.2

Fig.3

Remove the screw.

Remove the two screws.

Panel Assy

Tuner Amp Assy
