Pioneer DEH-X6500BT Service Manual

DEH-X65BT/XNUC
13
5 678
56
7
8
C
D
F
A
B
E
3.3 JIGS LIST
3.4 CLEANING
- Jigs List
- Grease List
Name
Grease
Grease
Grease
Grease
Grease No.
GEM1024
GEM1038
GEM1043
GEM1045
Remarks
CD Mechanism Module
CD Mechanism Module
CD Mechanism Module
CD Mechanism Module
Na
m
e
G
rease No.
R
emar
k
s
Name
16P FFC
Test Disc
L.P.F.
Acetate Tape
Silicon Glue
Jig No.
GGD1310
TCD-782
GYH1026
GEM1017
Remarks
Tuner Amp Unit - CD Core Unit
Checking the grating
Checking the grating (Two pieces)
Capacitor Bond Lock
Capacitor Bond Lock
Before shipping out the product, be sure to clean the
following portions by using the prescribed cleaning
tools:
Portions to be cleaned Cleaning tools
CD pickup lenses Cleaning liquid : GEM1004
Cleaning paper : GED-008

Pioneer DEH-X6500BT Specifications

General

MP3 playback	Yes
Preset stations quantity	24
Product color	Black
Volume control	Rotary
Disc types supported	CD, CD-R, CD-RW
Equalizer bands quantity	5
Display type	LCD
Display number of colors	210000 colors
USB version	2.0
Bluetooth profiles	A2DP, AVRCP, HFP, SSP
Line outputs (RCA)	2
USB ports quantity	1
Handheld remote control	No
Amplifier output power	200 W
