5. PCB PARTS LIST
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
561
473
R50
1R0
5621
NOTES:
560 Ω
47k Ω
0.5 Ω
1 Ω
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x 10
3
R50
1R0
561
473
5.62k Ω RN1/4PC F562 x 10
1
5621
Mark No. Description Part No.
LIST OF ASSEMBLIES
NSP 1..LOADING MECHA. ASSY VWT1207
NSP 2..LOAB ASSY VWG2426
1..DVDM ASSY VWS1556
NSP 1..FLKB ASSY VWM2171
2..FLKY ASSY VWG2408
NSP 2..IRKY ASSY VWG2415
NSP 2..SCRB ASSY VWV1934
>
1..POWER SUPPLY UNIT VWR1366
(or VWR1368)
Mark No. Description Part No.
A
LOAB ASSY [VWG2426]
SWITCHES AND RELAYS
S101 REAF SWITCH VSK1011
OTHERS
CN602 CONNCTOR S2B-PH-K
CN601 CONNCTOR S5B-PH-K
PRINTED CIRCUIT BOARD VNP1879
B
DVDM ASSY [VWS1556]
SEMICONDUCTORS
IC702 BA4560F
IC602 K4S641632F-TC75
IC101 M63018FP
>
IC401 MM1565AF
IC801 MM1623AF
>
IC703 NJM78L05UA
IC701 PCM1742KE
>
IC402, IC403 PQ1L333M2SP
IC400 PST3228
IC601 STM5589CVA
IC301 STM6316ATXXA
IC604 TC7WU04FU
IC603 VYW2061
Q390, Q753 2SA1576A
Q401, Q403 2SA1602A
Q202, Q212, Q402, Q730, Q791 2SC4081
Q746, Q748, Q756, Q758 2SD2114K
Q666 DTC114TUA
Q751, Q752 DTC114YUA
Q201, Q211 HN1A01F
Q603 RN4982
D730 1SS355
D603 RB501V-40
COILS AND FILTERS
L707 LAU4R7J
L390 LCYA2R7J2520
L361 CHIP BEADS VTL1083
CAPACITORS
C390 CCSRCH180J50
C142 CCSRCH221J50
C200, C717, C727, C756 CCSRCH331J50
C407, C409, C414, C421, C690 CCSRCH470J50
C713, C723 CCSRCH470J50
C392 CCSRCH560J50
C393, C640, C644 CCSRCH7R0D50
C211 CEAT100M50
C408, C615, C621, C651, C703 CEAT101M10
C705, C711, C721, C731, C801 CEAT101M10
C804 CEAT101M10
C301, C701 CEAT102M6R3
C792 CEAT1R0M50
C201 CEAT220M25
C715, C725, C733 CEAT470M16
C822, C832 CEAT471M6R3
C401 CKSQYB225K10
C127, C128, C381 CKSRYB102K50
C112–C114, C124, C125, C130 CKSRYB103K50
C134, C136, C355 CKSRYB103K50
C300 CKSRYB104K16
C394 CKSRYB152K50
C126, C344 CKSRYB223K50
C712, C722 CKSRYB391K50
C230, C232, C233, C309, C310 CKSRYF104Z25
C315, C318, C323, C326, C342 CKSRYF104Z25
C348, C357, C373, C377, C388 CKSRYF104Z25
C391, C402, C403, C603, C641 CKSRYF104Z25
C702, C704, C706, C714, C732 CKSRYF104Z25
C791, C802, C803, C805 CKSRYF104Z25
C811, C812, C851, C861 CKSRYF104Z25
C102, C132, C139, C415, C480 CKSRYF105Z10
C604, C607, C614, C619 CKSRYF105Z10
C622–C630, C636, C637 CKSRYF105Z10
C647, C648, C650, C659, C664 CKSRYF105Z10
C684, C698, C707, C821, C831 CKSRYF105Z10
C841 CKSRYF105Z10
Mark No. Description Part No.
