7.1.6 MECHANICAL ERROR HISTORY
Indication contents
• List of the error codes • List of the servo states
Note : 0 x & &
code
(Only this part is displayed to a display)
1
2
3
Description of the mechanical error history
1 Error number
The first two digits are for the error code, and the second
two digits are for the servo state.
2 Error number
The elapsed time from the time when the system was
turned on until an error was generated is displayed.
Note: If a later error time is shorter than the previous
error time, it means that the unit was turned off
then on again.
3 Description of errors
Error messages are displayed.
Example: If the error code is 0x13 (Focus lost timeout)
and the servo state is 0x05 (Disc judge), the
message becomes "Focus lost timeout in Disc
judge."
Only if a mechanical error (FE error) has been generated, a mechanical error history containing up to the last eight errors is
displayed if you press the CHP/TIM key in Service Mode.
Errors are displayed in descending order, with the latest one at the top.
Error Code
Servo State
1
2
3
0x00 Reset
0x01 Stop (inside position)
0x02 Stop (any position)
0x03 Braking for stop
0x04 New disc
0x05 Disc judge
0x06 Reserved 1
0x07 Playing
0x08 Start up
0x09 Seeking
0x0A Pausing
0x0B Reading BCA
0x0C Reserved 2
Tray open
Tray moving
0x0D
0x0E
0x0F
FOCUS ERROR 0x0∗ FOCUS TIMEOUT 0x1∗
Focus on error 0x01 Focus on timeout 0x11
Focus off error 0x02 Focus off timeout 0x12
Focus lost error 0x03 Focus lost timeout 0x13
Focus balance adjust error 0x04 Focus balance adjust timeout 0x14
Focus gain adjust error 0x05 Focus gain adjust timeout 0x15
Focus sweep error 0x06 Focus sweep timeout 0x16
Focus reflection error 0x07 Focus reflection timeout 0x17
TRACKING ERROR 0x2∗ TRACKING TIMEOUT 0x3∗
Tracking on error 0x21 Tracking on timeout 0x31
Tracking off error 0x22 Tracking off timeout 0x32
Tracking lost error 0x23 Tracking lost timeout 0x33
Tracking balance adjust error 0x24 Tracking balance adjust timeout 0x34
Tracking gain adjust error 0x25 Tracking gain adjust timeout 0x35
STEPPING ERROR 0x4∗ STEPPING TIMEOUT 0x5∗
Stepping on error 0x41 Stepping on timeout 0x51
Stepping off error 0x42 Stepping off timeout 0x52
Stepping lost error 0x43 Stepping lost timeout 0x53
Stepping move error 0x44 Stepping move timeout 0x54
SPINDLE ERROR 0x6∗ SPINDLE TIMEOUT 0x7∗
Spindle on error 0x61 Spindle on timeout 0x71
Spindle off error 0x62 Spindle off timeout 0x72
Spindle lost error 0x63 Spindle lost timeout 0x73
Spindle CAV error 0x64 Spindle CAV timeout 0x74
Spindle CLV error 0x65 Spindle CLV timeout 0x75
ACQUISITION ERROR 0x8∗ ACQUISITION TIMEOUT 0x9∗
PLL lost error 0x83 PLL lost timeout 0x93
DECODER ERROR 0xa∗ DECODER TIMEOUT 0xb∗
ID lost error 0xa3 ID lost timeout 0xb3
DEVICE ERROR 0xd∗
SRAM error 0xd1
Note: When an error has been generated, if the servo state
is "Disc judge," the disc tray opens, and if the servo
state is other than "Disc judge," the unit stops
(excluding a case of a device error with the error
code 0xd∗).
