Error Name No. Causes Check Item Possibility of Trouble
Remarks
FOCUS ERROR (0 x 0∗)
Focus on error 0 x 01 Focus on could not be completed
Are not there a dirt or a scratch in
the Disc? Does LD become weak?
Does the lens move up and down?
1. Pickup
2. Driver
3. Front End IC
Focus off error 0 x 02 Focus off could not be completed Unknown
Focus lost error 0 x 03 Focus servo is lost
Are not there a dirt or a scratch in
the Disc? Does LD become weak?
1. Pickup
Focus balance adjust error 0 x 04 AFB on could not be completed
Focus gain adjust error 0 x 05 Focus AGC could not be completed
Focus sweep error 0 x 06
Focus reflection error 0 x 07
Dimensions of S curve did not reach to the aim value
Does LD become weak? 1. Pickup
FOCUS TIMEOUT (0 x 1∗)
Focus on timeout 0 x 11 Did timeout at focus on
Are not there a dirt or a scratch in
the Disc? Does LD become weak?
Does the lens move up and down?
1. Pickup
2. Driver
3. Front End IC
Focus off timeout 0 x 12 Did timeout at focus off
Focus lost timeout 0 x 13 Did timeout at focus backup
Focus balance adjust timeout 0 x 14 Did timeout at AFB
Focus gain adjust timeout 0 x 15 Did timeout at AGC
Focus sweep timeout 0 x 16
TRACKING ERROR (0 x 2∗)
Tracking on error 0 x 21 Tracking on could not be completed
1. Pickup
2. Driver
3. Front End IC
Tracking off error 0 x 22 Tracking off could not be completed
Tracking lost error 0 x 23 Tracking servo is lost 1. Pickup
Tracking balance adjust error 0 x 24 ATB could not be completed 1. Pickup
Tracking gain adjust error 0 x 25 AGC could not be completed 1. Pickup
Tracking jump error 0 x 26 Tracking jump could not be completed
TRACKING TIMEOUT (0 x 3∗)
Tracking on timeout 0 x 31 Did timeout at tracking on
Are not there a dirt or a scratch in
the Disc?
1. Pickup
2. Driver
3. Front End IC
Tracking off timeout 0 x 32 Did timeout at tracking off
Tracking lost timeout 0 x 33 Did timeout at tracking backup
Are not there a dirt or a scratch in
the Disc?
1. Pickup
Tracking balance adjust timeout 0 x 34 Did timeout at ATB 1. Pickup
Tracking gain adjust timeout 0 x 35 Did timeout at AGC 1. Pickup
Tracking jump timeout 0 x 36 Did timeout at tracking jump
STEPPING ERROR (0 x 4∗)
Stepping on error 0 x 41 Stepping on could not be completed
1. Pickup
2. Driver
3. Front End IC
Stepping off error 0 x 42 Stepping off could not be completed
Stepping lost error 0 x 43 Stepping servo is lost
Stepping move error 0 x 44 Stepping could not move
Do move to inner and outer periphery
of the
stepping
in the test mode?
Do indicate "S-04" at the most inner
periphery of the
stepping
?
1. Stepping motor
2. Inside switch
3. Driver
STEPPING TIMEOUT (0 x 5∗)
Stepping on timeout 0 x 51 Did timeout at stepping on
1. Pickup
2. Driver
3. Front End IC
Stepping off timeout 0 x 52 Did timeout at stepping off
Stepping lost timeout 0 x 53 Did timeout at stepping backup
Stepping move timeout 0 x 54 Did timeout at stepping movement
Do move to inner and outer periphery
of the
stepping
in the test mode?
Do indicate "S-04" at the most inner
periphery of the
stepping
?
1. Stepping motor
2. Inside switch
3. Driver
ERROR CODE TABLE
