Pioneer GM-D9605 Service Manual

GM-D9605/XEEL
6
1234
1234
C
D
F
A
B
E
3. BASIC ITEMS FOR SERVICE
3.1 CHECK POINTS AFTER SERVICING
3.2 JIGS LIST
To keep the product quality after servicing, please confirm following check points.
demrifnocebotmetIserudecorP.oN
1 Confirm whether the customer complain has
been solved.
The customer complain must not be
reappeared.
Audio and operations must be normal.
2 Check the output sound. Audio and operations must be normal.
retfaecnaraeppastinotridrosehctarcsoNkcehcecnaraeppA3
receiving it for service.
See the table below for the items to be checked regarding audio:
Item to be checked regarding audio
Distortion
Noise
Volume too low
Volume too high
Volume fluctuating
Sound interrupted
- Jigs List
Bond
Bond
GYL1006
TB1401B or TB1401M
Applying to choke coil, resistor and capacitor
For fixing screws (Made by ThreeBond)
Name Jig No. Remarks
- Grease List
Grease GEM1057 Applying to Heatsink
Name Grease No. Remarks

Pioneer GM-D9605 Specifications

General

Bass boost	0 - 18 dB
Amplifier class	F/D
High pass filter	Yes
RMS output power (max)	2000 W
Signal-to-Noise Ratio (SNR)	94 dB
Number of amplifier channels	5 channels
RMS power output per channel (2 Ohm)	100 W
RMS power output per channel (4 Ohm)	75 W
Maximum power output per channel (4 Ohm)	150 W
Audio RCA inputs	6
Product color	Black

Weight and Dimensions

Depth	200 mm
Width	315 mm
Height	51 mm
