Pioneer PD-F1007 Service Manual

PD-F1007
30
Mark No. Description Part No.
Mark No. Description Part No.
5. PCB PARTS LIST
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
561
473
R50
1R0
5621
NOTES:
560
47k
0.5
1
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x 10
3
R50
1R0
561
473
5.62k RN1/4PC F562 x 10
1
5621
LIST OF PCB ASSEMBLIES
NSP MOTHER BOARD ASSY PWM2252
MAIN BOARD ASSY PWZ3822
NSP MECHANISM BOARD ASSY PWX1572
NSP SENSOR BOARD ASSY PWZ3781
NSP SELECT BOARD ASSY PWZ3785
NSP LOADING BOARD ASSY PWZ3788
NSP LOADING SW BOARD ASSY PWZ3790
NSP RADIATE BOARD ASSY PWZ3791
NSP RECIEVE BOARD ASSY PWZ3792
NSP SUB BOARD ASSY PWX1576
DISPLAY BOARD ASSY PWZ3839
NSP FUNCTION BOARD ASSY PWZ3847
POWER BOARD ASSY PWZ3852
NSP HEADPHONE BOARD ASSY PWZ3860
NSP DOOR MOTOR BOARD ASSY PWZ3863
NSP DOOR SW BOARD ASSY PWZ3865
VOLUME BOARD ASSY PWZ3866
NSP LED BOARD ASSY PWZ3867
NSP SERVO MECHANISM ASSY GM PXA1591
MECHANISM BOARD ASSY PWX1192
MECHANISM BOARD ASSY
SWITCHES AND RELAYS
S610 DSG1016
OTHERS
CN610 MT CONNECTOR 173979-4
SENSOR BOARD ASSY
SEMICONDUCTORS
Q604 2SC1740S
Q601, Q602 DTC124ES
D601, D602 GP1S58V
RESISTORS
All Resistors RD1/4PU J
OTHERS
CABLE HOLDER 51048-0300
CABLE HOLDER 51048-0700
J603 3P JUMPER WIRE D20PDD0310E
J602 7P JUMPER WIRE D20PDD0725E
J605 3P JUMPER WIRE D20PDY0310E
SELECT BOARD ASSY
OTHERS
CABLE HOLDER 51048-0700
CABLE HOLDER 51048-0900
J601 9P JUMPER WIRE D20PDY0930G
LOARDING BOARD ASSY
OTHERS
CABLE HOLDER 51048-0300
CABLE HOLDER 51048-0500
J652 3P JUMPER WIRE D20PDD0310E
J651 5P JUMPER WIRE D20PDY0530E
LOARDING SW BOARD ASSY
OTHERS
CABLE HOLDER 51048-0300
REAF SWITCH VSK1011
RADIATE BOARD ASSY
SEMICONDUCTORS
D611 GL381J
OTHERS
CABLE HOLDER 51048-0300
L.E.D. HOLDER RNK1795
