Pioneer PD-F1007 Service Manual

PD-F1007
55
8. PANEL FACILITIES AND SPECIFICATIONS
PANEL FACILITIES
FRONT PANEL
Lights when the BEST button is
pressed.
Lights when the remaining time
is displayed.
Lights during random play.
Lights during repeat play.
Lights when the PROGRAM
(PGM) button is pressed.
Lights when a CD
is being played.
Lights during pause
mode.
Blinks when the PREVIOUS button is
pressed.
Blinks during DISC SCAN,
DISC TITLE SCROLL or
DISC TITLE INPUT.
Lights during custom program-
ming and play.
Lights when you choose
the play mode.
DISPLAY
POWER switch
SINGLE LOADER
ACCESS button
Hood
Remote sensor
PROGRAM
button
PHONES jack
Terminal for inserting
headphones plug
PHONES LEVEL
control
Adjust the volume level
Track/Manual
search button
(forward direction)
(¡¢)
RANDOM button
OPEN/CLOSE
button
UNLOAD button
MODE button
CLEAR button
SINGLE LOADER PLAY button
STANDBY
indicator
Stop button (7)
Play/Pause button
(6)
Track/Manual search
button (reverse direction)
(41)
TITLE/DISPLAY
button
TITLE/SEARCH
button
TITLE/INPUT
button
TIME/CHARA
button
Jog dial
DIRECT CUSTOM
buttons
Blinks during TRACK SCAN
or TRACK TITLE SCROLL.
Blinks during DISC SCAN or
TRACK SCAN.
Lights when a CD TEXT
is being played.
ENTER

Pioneer PD-F1007 Specifications

General

Frequency range	2 - 20000 Hz
Signal-to-Noise Ratio (SNR)	98 dB
CD Text	Yes
Device type	HiFi CD player
Product color	Black
I/O ports	Optical Digital Output One More 300CD's Connect Headphone Output with Volume Control Keyboard Input
Dimensions (WxDxH)	420 x 433 x 193 mm

Weight and Dimensions

Weight	8000 g
