Pioneer PE6000 Series User Manual

Description of Function Codes PE6000 User Manual
172
It is used to set the overvoltage threshold of the AC drive. The default values of different
voltage classes are listed in the following table.
Voltage Class Default Overvoltage Threshold
Single-phase 220 V 400.0 V
Three-phase 220 V 400.0 V
Three-phase 380 V 810.0 V
Three-phase 480 V 890.0 V
Three-phase 690 V 1300.0 V
Three-phase 1140 V 2000.0V
NOTE: The default value is also the upper limit of the AC drive's internal overvoltage protection
voltage. The parameter becomes effective only when the setting of A5-09 is lower than the default
value. If the setting is higher than the default value, use the default value.
Group A6: AI Curve Setting
A6-00
AI curve 4 minimum input Default 0.00 V
Setting Range -10.00 V to A6-02
A6-01
Corresponding setting of AI curve 4
minimum input
Default 0.00 V
Setting Range -100.0%–100.0%
A6-02
AI curve 4 inflexion 1 input Default 3.00 V
Setting Range A6-00 to A6-04
A6-03
Corresponding setting of AI curve 4
inflexion 1 input
Default 30.00 V
Setting Range -100.0%–100.0%
A6-04
AI curve 4 inflexion 1 input Default 6.00 V
Setting Range A6-02 to A6-06
A6-05
Corresponding setting of AI curve 4
inflexion 1 input
Default 60.0%
Setting Range -100.0%–100.0%
