Pioneer PE6000 Series User Manual

Function Code Tables PE6000 User Manual
46
Function
Code
Parameter Name Setting Range Default Modification
P0-07
Frequency source
selection
Unit's digit (Frequency source
selection)
00
☆
0: Main frequency source X
1: X and Y operation
(operation relationship
determined by ten's digit)
2: Switchover between X and Y
3: Switchover between X and
"X and Y operation"
4: Switchover between Y and
"X and Y operation"
Ten's digit (X and Y operation
relationship)
0: X+Y
1: X-Y
2: Maximum
3: Minimum
4: X×Y
P0-08 Preset frequency
0.00 to maximum frequency
(P0-10)
50.00Hz
☆
P0-09 Rotation direction
0: Same direction
1: Reverse direction
0
☆
P0-10 Maximum frequency 50.00–600.00 Hz 50.00 Hz
★
P0-11
Source of frequency
upper limit
0: Set by P0-12
1: AI1
2: AI2
3: Keyboard potentiometer
4: Pulse setting
5: Communication setting
0
★
P0-12 Frequency upper limit
Frequency lower limit (P0-14)
to maximum frequency (F0-10)
50.00 Hz
☆
P0-13
Frequency upper limit
offset
0.00 Hz to maximum frequency
(F0-10)
0.00 Hz
☆
P0-14 Frequency lower limit
0.00 Hz to frequency upper
limit
(F0-12)
0.00 Hz
☆
P0-15 Carrier frequency 0.5–16.0 kHz
Model
dependent
☆
P0-16
Carrier frequency
adjustment with
temperature
0: No
1: Yes
1
☆
P0-17 Acceleration time 1 0.00–65000.00s
Model
dependent
☆
P0-18 Deceleration time 1 0.00–65000.00s
Model
dependent
☆
