Description of Function Codes PE6000 User Manual
90
Function
Code
Parameter Name Setting Range Default
P1-06
Stator resistance
(asynchronous motor)
0.001–65.535 Ω (AC drive power ≤ 55
kW) 0.0001–6.5535 Ω (AC drive power >
55 kW)
Model
dependent
P1-07
Rotor resistance
(asynchronous motor)
0.001–65.535 Ω (AC drive power ≤ 55
kW) 0.0001–6.5535 Ω (AC drive power >
55 kW)
Model
dependent
P1-08
Leakage inductive
reactance
(asynchronous motor)
0.01–655.35mH (AC drive power ≤ 55
kW) 0.001–65.535mH (AC drive power >
55 kW)
Model
dependent
P1-09
Mutual inductive
reactance
(asynchronous motor)
0.1–6553.5mH (AC drive power ≤ 55 kW)
0.01–-655.35mH (AC drive power >
55 kW)
Model
dependent
P1-10
No-load current
(asynchronous motor)
0.01 to P1-03 (AC drive power ≤ 55 kW)
0.1 to P1-03 (AC drive power > 55 kW)
Model
dependent
The parameters in P1-06 to P-10 are asynchronous motor parameters. These parameters are
unavailable on the motor nameplate and are obtained by means of motor auto-tuning. Only P1-06
to P1-08 can be obtained through static motor auto-tuning. Through complete motor auto-tuning,
encoder phase sequence and current loop PI can be obtained besides the parameters in P1-06 to
P1-10.
Each time "Rated motor power" (P1-01) or "Rated motor voltage" (P1-02) is changed, the AC
drive automatically restores values of P1-06 to P1-10 to the parameter setting for the common
standard Y series asynchronous motor.
If it is impossible to perform motor auto-tuning onsite, manually input the values of these
parameters according to data provided by the motor manufacturer.
Function
Code
Parameter Name Setting Range Default
P1-37 Auto-tuning selection
0: No auto-tuning
1: Asynchronous motor static auto-tuning
2: Asynchronous motor complete
auto-tuning
3: Synchronous motor static complete
auto-tuning
0
•
0: No auto-tuning
Auto-tuning is prohibited.
•
1: Asynchronous motor static auto-tuning
It is applicable to scenarios where complete auto-tuning cannot be performed because the
