Pioneer SC-LX81 Service Manual

92
SC-LX81
1
2 3 4
A
B
C
D
E
F
1
2 3 4
9.5 FRONT PANEL SECTION
CONTACT SIDE
NON-CONTACT
SIDE
Double Side Tape
10 X 35
REG
CN7621
D-MOTHER
CN2002
∗a
∗a
∗b ∗b
∗e
∗e
∗c
∗d
∗d
Cut Cut
Cut
Cut
A
A
HDMI NETWORK CN801
D-MOTHER CN2401
INTERFACE CN7062
INTERFACE
JH7061
M
K
L
C
Paste lubricant floil (GYA1001)
to Earth Spring and Door Base.
Floil
GYA1001
Lubricant
