25
Connecting your equipment (In case of VSX-90)
03
Installing your speaker system
At the very least, front left and right speakers only are necessary. Note that your main surround speakers should
always be connected as a pair, but you can connect just one surround back speaker if you like (it must be con-
nected to the left surround back terminal).
Standard surround connection
! When only connecting one surround back speaker, connect it to the SURROUND BACK L (Single) terminals.
A
TOP MIDDLE
SURROUND
SURROUND BACK
CENTER
5.2.2ch
5.2ch
SPEAKER B
5.2.2ch
HDZONE / BI-AMP
FRONT
RLRL
RL
RL
(Single
)
B
7.2ch
SUBWOOFER
PRE OUT
1
2
AUDIO OUT
A
TOP MIDDLE
SURROUND
SURROUND BACK
CENTER
5.2.2ch
5.2ch
SPEAKER B
5.2.2ch
HDZONE / BI-AMP
FRONT
RLRL
RL
RL
(
Single
)
B
7.2ch
SUBWOOFER
PRE OUT
1
2
AUDIO OUT
LINE LEVEL
INPUT
LINE LEVEL
INPUT
The top middle terminals can also be used for the front wide and Speaker B speakers.
Top middle right To p middle left
7.2 ch SB/FW setting
Front wide right Front wide left
Speaker B setting
Speaker B - right Speaker B - left
Front right Center Subwoofer 2Subwoofer
ront left
Surround back speaker terminals can be
used to connect to the sub zone.
Surround left
7.2 ch/5.2.2 ch setting
Surround back right Surround back left
Surround back right Surround back left
Surround back right Surround back left
ZONE 2 setting
ZONE 2 - Right ZONE 2 - Left
HDZONE setting
HDZONE - Right HDZONE - Left
Surround right
7.2 ch/5.2.2 ch setting
7.2 ch SB/FW setting
Speaker B setting
Dolby Enabled Speaker
Dolby enabled speakers bring a new sense of height and immersion to the listening experience without installa-
tion of overhead speakers.
Ceiling
Listener
Dolby Enabled
Speaker
The front or surround speaker and Dolby Enabled Speaker are explained as one product group for the following
connections. Connect the Standard surround connection on page 25 of the TOP MIDDLE terminal when using
a Dolby Enabled Speaker as an independent product.
To Next Page
