DP-20 WEB GUIDE CONTROLLER USER MANUAL
10
10-1
10 SPECIFICATIONS
General
Universal Input Line - 100 VAC -10% to
Voltage Range 240 VAC +10%
Input Line Frequency - 47-63 Hz
Power consumption - 130 VA
Internal Fuse - 3.15 A (not user serviceable)
Operating Ambient - 0° to 50°C (32° to 122°F)
Temperature
Dimensions - Height 144 mm (5.67”)
Width 144 mm (5.67”)
Depth 103 mm (4.06”) (without cables attached)
Approximate Weight - 1.6 Kg (3.5 lbs)
Inputs and Outputs
Electromechanical Actuator - Maximum 39 W at 30 V
Hydraulic Servo Valve - ±50 mA
With or without Lockout Valve (Max 39 W at 24 V or 48 V)
MPA (with MPA Lockout Signal) - ±10 mA
ServoCenter - Analog Inductive type
Sensor Input (2) Individually - Max Input ±20 mA
Programmable 0 to 10 mA (Preferred)
Parallel port - Six Digital Inputs
Low Level: 0 – 0.9 V
High level: 3.6 – 24 V, max 6 mA
Two open collector outputs connected to ground, max 30 V
(NPN open collector) 55 mA at 1.6 V
+12 V available to port for input reference
Supply to Accessories - +12V±5%, 400mA
-12V±5%, 150mA
06-05-2007 DP-20 WEB GUIDE CONTROLLER Figure Sheet 1-862-D
