98
SPECIFICATIONS
RANGER 400 HO
Maximum Weight Capacity 1000 lbs. (454 kg) (includes weight of operator,
passenger, cargo, accessories)
Dry Weight 1050 lbs. (476 kg)
Fuel Capacity 8.8 gal. (33.3 l)
Engine Oil Capacity 2 qts. (1.9 l)
Coolant Capacity 2.25 qts. (2.4 l)
Overall Length 108 in. (274.3 cm)
Overall Width 56.5 in. (143.5 cm)
Overall Height 73 in. (185 cm)
Wheelbase 72 in. (183 cm)
Cargo Box (L x W x H) 58 x 42 x 10 in. (147 x 106.7 x 25.4 cm)
Ground Clearance 10 in. (25.4 cm)
Min. Turning Radius 150 in. (381 cm)
Towing Capacity 1250 lbs. (567 kg)
Max. Cargo Box Load 500 lbs. (227 kg)
Engine 4 valve 4 stroke single cylinder with
counter balance
Lubrication System Dry Sump
Cooling Liquid
Engine Oil 0W/40
Displacement 455 cc
Bore x Stroke (mm) 87.9 x 75
Pilot Jet 42.5
Main Jet 150
Needle Jet P-6 (829)
Jet Needle 4IB33
Air Screw 2.75
Alternator Output 250 W
Compression Ratio 9.7:1
Starting System Electric
Carburetor 34 mm
Ignition System CDI
Ignition Timing 30° @5000 RPM
Spark Plug NGK BKR6E
Front Suspension Strut w/8 in. (20.3 cm) of travel
Rear Suspension Independent w/9 in. (23 cm) of travel
