4.27
ELECTRONIC FUEL INJECTION
4
7. Remove the rear seat support by removing the 5/16”
fastener and 7/16” fastener retaining the right side of the
rear seat support. Remove the 7/16” fastener from the left
side of the rear seat support. Remove the rear seat support
from the vehicle.
8. Remove both fuel tank bracket fasteners. Move the fuel
tank brackets out of the way for removal of fuel tank.
9. Disconnect the fuel pump electrical harness.
10. Remove the fuel tank vent hose clamp with a suitable pliers
and remove the vent line from the tank vent fitting.
11. While holding a shop towel over the fuel line connector,
disconnect the quick connect fuel line from the fuel pump.
Move the fuel line out of the way for tank removal.
NOTE: A small amount of fuel may come out of the
fuel line or tank. Properly drain fuel into a suitable
container.
Remove
Do Not Remove
Remove
Only remove this
fastener from the
left side of the
rear seat support
Tank Bracket
Fasteners
Tank Brackets
Disconnect
Here
