Powermate M-2C User Manual

U
ps
t
a
i
rs
1 Manoeuver the PowerMate
®
backwards to the first
step as shown in “A”, just near enough to allow the
wheels to clear the edge of the treads when raised
as shown in “B”.
2 Pivot the PowerMate
®
on the heel of the toe plate
as shown in “B”. Push the “LOAD DOWN” button to
raise the wheels to rest on step 2.
3 Raise the toe plate off the ground, pivoting on the
wheels of the
PowerMate
®
. Push the “LOAD UP”
button, raising the
PowerMate
®
frame and load and
resting the frame on step 1 as shown in “C”.
4 Pivot the PowerMate
®
on the load frame so
that the wheels are clear of the steps and push
the “LOAD DOWN” button to raise the wheels
to step 3 as shown in “D”.
Repeat procedures 3 and 4 until the top of the stairs are
reached.
POWERMATE OPERATION
STAIR CLIMBING
PowerMate
®
Operation Manua
l
Down Stairs
1. Position the PowerMate
®
at the top of the stairs with
the load frame overhanging and clear of the steps.
Push the “LOAD DOWN” button to lower the load
and load frame, and rest it on step 2 as shown in
“E”.
2. Pivot the PowerMate
®
on the heel of the load frame
and push the “LOAD UP” button which will lower
the wheels to step 3 as shown in “F”.
3. Pivot the PowerMate
®
on its wheels to lift the load
frame clear of the steps and push the “LOAD
DOWN” button to lower the load frame to rest on
the toe plate on step 1.
Repeat procedures 2 and 3 until reaching the
bottom of the stairs.
PN 010340 Rev.E
Eng. 05/ 08/ 14
3.04
