Powermate M-2C User Manual

PowerMate
®
Operation Manua
l
STRAPBAR ASSEMBLY M-SERIES
REPLACEMENT STRAP INSTALLATION
TOOLS REQUIRED: 7/16"Wrench, 5/16"Flat Screw Driver.
PARTS LIST
DESCRIPTION
PART No.ITEM
STRAPBAR M-SERIES
3057501
FELT STRAP BAR 1/4"x 2"x 23"
1019602
CAM HANDLE
3021103
CAM
3100404
SET SCREW 5/16-18 x 5/16050990
5
BOLT 5/16-18 x 3/4"
0507706
LOCK NUT 5/16-18NC050620
7
STRAP 10' c/w TOGGLE
STRAP 12' c/w TOGGLE
STRAP 14' c/w TOGGLE
STRAP 16' c/w TOGGLE
310530
300500
300600
300490
8
PAN HEAD SCREW 1/4-20x3/40503009
LOCK NUT 1/4-20NC
05061010
2
1
3
4
5
6
77
99 6
1010
8
PN 010640 Rev.E
Eng. 05/ 08/ 14
Steel Strapbar
1/4"Locknut
(2) 1/4-20NC X 3/4"
Pan Head Screw
1/4"Locknut
Replacement Strap and Toggle
Head of screws must be oriented inwards.
This is done to prevent chaffing on strap.
STRAP BAR ASSEMBLIES:
400080S - 10 ft. Strap
400082S - 12 ft. Strap
400084S - 14 ft. Strap
400086S - 16 ft. Strap
REPLACEMENT STRAP/
TOGGLE KITS AVAILABLE
(Comes with fastener hardware):
400310 - 10 ft. Strap
400320 - 12 ft. Strap
400300 - 14 ft. Strap
400340 - 16 ft. Strap
Washers in Kits
not required.
5.07
