Troubleshooting
Troubleshooting with LEDs
A-2 FC0054606-00 A
S
Table A-2. QLA234x/QLA210/QLE220 Adapter LED Scheme
Green LED Amber LED Activity
❍ ❍ Power off
●●Power
● ❍ Online
❍●Link
❍ Flashing Loss of synchronization
Alternate
flashing
Alternate
flashing
Firmware error
Flashing ❍ Beacon
Table A-3. QLA24xx/QLE24xx/QEM2462 Adapter LED Scheme
Yellow LED Green LED Amber LED Activity
❍ ❍ ❍ Power off
●●●Power on (before firmware init)
Flashing Flashing Flashing Power on (after firmware init)
Yellow, green, and amber LEDs flashing
alternately
Firmware error
❍ ❍ ●/Flashing Online, 1Gbps link / I/O activity
❍●/Flashing ❍ Online, 2Gbps link / I/O activity
●/Flashing ❍ ❍ Online, 4Gbps link / I/O activity
Flashing ❍ Flashing Beacon
