A – Specifications
Dimensions
59265-00 A A-5
A
Dimensions
Electrical
Power Cord Specifications
The switch comes with one or two power cords with NEMA 5-15 non-locking plugs
(SKU: CPK-9000-US). This power cord is approved for North America (USA,
Canada, Puerto Rico), Mexico, Central America, South America, Korea, Taiwan,
Phillippines, and Thailand. A similar power cord with a locking plug is also
available ((SKU: CPK-9000-USL). QLogic offers power cords for additional
regions/countries as listed in Table A-6.
Table A-4. Dimensional Specifications
Width...............................................
Height .............................................
Depth..............................................
17” (432 mm), 19 inch rack mount
1.70” (43.2 mm) (1U)
19.69” (500 mm)
Weight............................................. 18 lbs (8.16 Kg)
Table A-5. Electrical Specifications
Operating voltage ........................... 100 to 240 VAC; 50 to 60 Hz
Power source loading (maximum).. 1 A at 120 VAC
0.5 A at 240 VAC
Heat Output (maximum) ................. 120 watts
Circuit Protection ............................ Internally fused
Table A-6. Availalbe Power Cords
Region/Country Specification
QLogic SKU
Number
Argentina IRAM 2073.1982 Plug CPK-9000-AR
Australia AS/NZS 3112 Plug CPK-9000-AUNZ
Bahrain BS1363/A Plug CPK-9000-UKHK
China (PRC) GB2099/GB1002-1 Plug CPK-9000-CN
Denmark Data DK-2-5A Plug CPK-9000-DK
