59265-00 A 2-1
2 General Description
The SANbox 5802V switch, shown in Figure 2-1, is a 24-port 8-Gbps Fibre
Channel switch with both Ethernet and serial management interfaces. This
section describes the features and capabilities of the SANbox 5802V switch and
includes information about the following features:
Chassis Controls and LEDs
Fibre Channel Ports
Ethernet Port
Power Supplies and Fans
Switch Management
Fabrics are managed with the Command Line Interface (CLI) or the QuickTools
web applet.
Refer to SANbox 5802V Fibre Channel Switch Command Line Interface
Guide for more information about the CLI.
Refer to the SANbox 5802V QuickTools Switch Management User Guide for
information about QuickTools.
Figure 2-1 SANbox 5802V Fibre Channel Switch
