4 – Installation
Installing a Switch
59265-00 A 4-3
A
Installing a Switch
Unpack the switch and accessories. The SANbox 5802V product is shipped with
the components shown in Figure 4-1:
SANbox 5802V Fibre Channel (1) with firmware installed
Power cords (2)
Rubber feet (4)
Figure 4-1 SANbox 5802V Fibre Channel
Installing a SANbox 5802V switch involves the following steps:
1. Mount the Switch
2. Install Transceivers
3. Configure the Workstation
4. Connect the Switch to AC Power
5. Connect the Workstation to the Switch
6. Configure the Switch
7. Cable Devices to the Switch
