5-12 Operation and Maintenance
62-0162-01
Loading the Data Cartridge
Due to static the label or other items included in this
package will occasionally cling to the DLT cartridge.
Before loading into a drive, ensure that all other items from
this package are separated from the cartridge.
Never press in on the hub portion of the data cartridge.
Step 1 If you are planning to write data to, or erase data
from, the cartridge, make sure the
Write-Protect
switch
on the cartridge is in the write-enabled position (all
the way to the right).
A data cartridge can only be loaded when the
O
erate
Handle
LED is ON. Do not attempt to open the
Cartrid
e
Insert/Release Handle
unless this LED is ON steady.
Step 2 Lift up on the
Cartrid
e Insert/Release Handle
.
Figure 5-1 Loading a Data Cartridge
Caution
Caution
