Loading a cartridge
1. Lift the cartridge door (4) and insert the cartridge into the slot in the front of the drive with the
arrow uppermost and facing the drive door(2).
2. Arrow indicates leading direction1. Label area
4. Cartridge door3. Ready light
Figure 11 Inserting a cartridge
2. Apply gentle pressure until the drive takes the cartridge and loads it. (See figure above.)
3. The Ready light (3) flashes green while the drive performs its load sequence. When the cartridge
is loaded, the Ready light shows steady green.
Unloading a cartridge
CAUTION: Never try to remove a cartridge before it is fully ejected.
18 Operating your tape drive
