GNSS Module Series
L76_Series_EVB_User_Guide 11 / 31
3 Board User Interfaces
3.1. EVB Top View
EVB top view is shown in the figure below.
U101
L76 series module
J106
Test points
J301
UART connector
S101
STANDBY switch
D101
1PPS and TXD
indication LEDS
J101
Antenna connector
J201
Micro-USB connector
S201
Power switch
Z102
FORCE_ON button
Z101
RESET button
S301
UART USB swicth
EVB version
Figure 3: EVB Top View
3.2. Board User Interfaces
The EVB interfaces are detailed in the table below.
