Quectel L76 Hardware Design

GNSS Module Series
L76&L76-L_Hardware_Design 50 / 59
8 Product Handling
8.1. Packaging
All the three modules are delivered as a reeled tape, which enables efficient production, set-up and
dismantling of production batches. It is shipped in a vacuum-sealed packaging to prevent moisture intake
and electrostatic discharge.
8.1.1. Tapes
The following figure shows the position of the three modules when delivered in tape and the dimensions
of the tape.
6
P S
1
12
11
10
9
8
7
6
5
4
3
2
07
06
05
10
09
08
24.00
±0.3
11.50
±0.15
1.75
±0.1
4.00
±0.15
? 1.50
±0.15
16.00
±0.15
0.30±0.05
2.00
±0.15
10.10? à0.15
3.00? à0.15
10.10
±0.15
11.10
±0.15
11.10
±0.15
Unit: mm
Quantity per reel: 500pcs
Length per reel: 8.64m
330
28.5
13
100
24.5
Out direction
Figure 28: Tape and Reel Specifications
