M12 Hardware Design
M12_Hardware_Design_V3.3 - 15 -
might occur. For example, the frequency error or the phase error could increase.
Table 4: Coding schemes and maximum net data rates over air interface
Coding scheme
1 Timeslot
2 Timeslot
4 Timeslot
CS-1:
9.05kbps
18.1kbps
36.2kbps
CS-2:
13.4kbps
26.8kbps
53.6kbps
CS-3:
15.6kbps
31.2kbps
62.4kbps
CS-4:
21.4kbps
42.8kbps
85.6kbps
2.2. Functional diagram
The following figure shows a block diagram of M12 and illustrates the major functional parts.
Power management
Baseband
Serial Flash
The GSM radio frequency part
The Peripheral interface
Power supply
Turn on/off interface
UART interface
Audio interface
SIM interface
ADC
SD card interface
RF interface
Quectel
Confidential
