M35 User Manual
M35_User_Manual Confidential / Released 13 / 85
module usage. This module should NOT be installed and operating simultaneously with other radio.
The manual of the host system, which uses M35 must include RF exposure warning statement to advice
user should keep minimum 20cm from the radio antenna of M35 module depending on the Mobile status.
Note: If a portable device (such as PDA) uses M35 module, the device needs to do permissive change
and SAR testing.
The following list of antenna is indicating the maximum permissible antenna gain.
Part
Number
Frequency
Range (MHz)
Peak
Gain
(XZ-V)
Average Gain
(XZ-V)
VSWR
Impedance
3R007A
GSM850:
TX 824-849MHz
RX 869-894MHz
PCS1900：
TX 1850-1910MHz
RX 1930-1990MHz
1 dBi typ.
1 dBi typ.
3 max
50Ω
Antenna gain including cable loss must not exceed 4.95 dBi of GSM 850 and 2.5 dBi of PCS 1900 for th
e purpose of satisfying the requirements of 2.1043 and 2.1091. The antenna(s) used for this
transmitter must be installed to provide a separation distance of at least 20cm from all persons and
must not be co-located or operated in conjunction with any antenna or transmitter not described
under this FCC ID. The final product operating with this transmitter must include operating
instructions and antenna installation instructions, for end-users and installers to satisfy RF exposure
compliance requirements. Compliance of this device in all final product configurations is the
responsibility of the Grantee. Installation of this device into specific final products may require the
submission of a Class II permissive change application containing data pertinent to RF Exposure,
spurious emissions, ERP/EIRP, and host/module authentication, or new application if appropriate.
Installation of this device into specific final products may require the submission of a Class II
permissive change application containing data pertinent to RF Exposure, spurious emissions,
ERP/EIRP, and host/module authentication, or new application if appropriate.
2.3. Key Features
The following table describes the detailed features of M35 module.
Table 1: Module Key Features
Feature
Implementation
