Quicksilver 855WE — System & Component Overview and Operaon
24
Fresh Water System - Hot and Cold
Water tank ll
Water tank ll hose
Water tank vent
Water tank vent hose
Water tank
Tank to pump hose
Water pump
Water pump lter
Water pump to boiler tube
Boiler
Pump to galley sink tube
Boiler to galley sink tube
Galley sink faucet
Pump to head sink tube
Boiler to head sink tube
Head sink faucet
Pump to transom shower tube
Boiler to transom shower tube
Transom shower
3. Black Water System
Your vessel is equipped with a waste containment / disposal system. This includes a toilet water
pickup, an electric ush toilet, a 100 liter holding tank, macerator, discharge seacock, and a dockside
pump out connecon.
Operaon
Prior to using the toilet, make sure that the toilet water pickup valve, located under the interior oor
liner access cover, is opened. To operate, simply press and hold the switch located on the head sink
basin unl the bowl is thoroughly rinsed and there is no water at the base of the bowl. Refer to the
toilet owner's manual in regards to specic operaon of the toilet.
Macerator
The macerator gives the boat operator the means of discharging the holding tank directly overboard
through a seacock in the boom of the hull. The macerator control is located in the main baery
To Next Page
