9
1
3
2
If necessary
Make a sharp bend. Use the
elbow connector if a sharp
bend is desired.
1 Position the lter bracket
Position the bracket at least 5 cm below the sink or counter
top with at least 25 cm space between the bottom of the
bracket and the base of the cabinet.
2 Mount the lter bracket
Place a screw in the selected location and attach the lter
bracket. Secure the bracket with the two remaining screws.
3 Attach the lter
Remove the red cap from the new lter. Then screw on the
lter by turning it anticlockwise until it stops. Do not screw
it too tightly.
Installing the lter bracket
Min. 50 mm
Min. 250 mm
