RADWAG PS/X series User Manual

- 21 -
- equivalents of ENTER / PRINT key and ESC key
Accepting entered value of a parameter
Abandon parameter changes and exit to to main
menu
7.1.4. Moving through user menu using virtual keyboard, via RS 232
interface
Most of the functions controlled or set using keys on balance’s overlay or an external
computer keyboard PS/2 type can be carried out by a set of commands sent from a
computer to a balance.
The commands enable moving through user menu, setting parameters or controlling
balance operation. The list of commands is provided at the end of this user manual.
7.2. User menu - content
The content of balance’s menu is presented in point 6 of this user manual.
Menu structure of a balance PS/X series is described in point 5 of this user manual. When
in the main weighing window press Setup key to enter the main menu settings. The display
opens a list with main menu. By pressing up and down navigating arrows move the cursor
and place it next to a submenu to be edited.
Fig. 7. Balance main menu – submenu selection
In order to edit a submenu, press RIGHT ARROW key, which opens the content of
selected submenu. When inside the submenu structure, the user can select an option to be
edited (modified) by placing the cursor next to submenu name (use up and down
navigating arrows). When the cursor is placed next to desired option press RIGHT
ARROW key to enter submenu settings.
