RADWIN 5000 HPMP User Manual
Release 3.1.00
B-1
Appendix B
Wiring Specifications
ODU-PoE Cable
The ODU-PoE cable is shielded/outdoor class CAT-5e, 4 twisted-pair 24 AWG terminated with
RJ-45 connectors on both ends. A cable gland on the ODU side provides hermetic sealing.
The following table shows the connector pinout:
Table B-1: ODU-PoE RJ-45 Connector Pinout
Function
Color
IDU
ODU
Ethernet (RxN)
White/Green
1
1
Ethernet (RxT)
Green
2
2
Ethernet (TxT)
White/Orange
3
3
Ethernet (TxN)
Orange
6
6
Power (+)
Blue
4
4
Power (+)
White/Blue
5
5
Power ( )
White/Brown
7
7
Power ( )
Brown
8
8
ODU/HSS Unit Connection Pinout
Table B-2: ODU/HSS Unit Connection Pinout
Color
ODU
RJ-45
HSS UNIT
RJ-45
White/Green
1
1
Green
Not connected
White/Orange
Orange
6
6
Blue
4
4
White/Blue
5
5
