Appendix C: Setting the Channel Number
38
If you are using an ESP-SAT or ESP-SITE-Satellite
controller, each Maxicom
2
satellite on a CCU must
have a channel number for successful
communication.
To set the channel number,
1. Turn the dial on the controller’s faceplate to the
TIME/CALENDAR position.
2. Press the MAN. START/ADV. key on the
faceplate until the number “1” and the word
“CHAN” appear in the display.
3. Use the
▲/ON and ▼/OFF keys to select
the channel number you desire.
Note: If the satellite is a 32- or 40-station model,
the controller will operate the first 24 stations on
the channel number you select and the remaining
stations on the next number in the sequence. For
example, if you select channel 5 on a 40-station
satellite, stations 1-24 will operate on channel 5,
and stations 25-40 will operate on channel 6.
Warning! Never select channel 28 (on a CCU-28)
or channel 6 (on a CCU-6) for a 32- or 40-station
satellite. There are no channels higher than 28 for
the CCU-28 and no channels higher than 6 for the
CCU-6. Stations will not operate when assigned to
channels higher than 28 (CCU-28) or 6 (CCU-6).
Note: ESP-SITE Satellite controllers must be set
to channel 1.
