Raisecom RC552-FE User Manual

Page 15 of 25
Chapter 7 Network Management Features
6.1 Review the Module
When RC552-FE(A) module is inserted into 16-slot chassis with management agent card, customers can review the module
status and also configure the module. The following parameters can be reviewed or configured.
Numbe
r
Name of configurable item Value Attribute
1 Module type M/S1/S2/S3 Uncontrollable, non-configurable
2 Remote management (MASTER only) Enable/disable Configurable
3
Module voltage exceeds upper
threshold (SLAVE only)
Normal, up overflow Uncontrollable, non-configurable
4
Module voltage exceeds lower
threshold (SLAVE only)
Normal, low overflow Uncontrollable, non-configurable
5 Module temperature (SLAVE only) Actual temperature Uncontrollable, non-configurable
6
Remote module power off indication
(MASTER only)
Normal, power off Uncontrollable, non-configurable
7 Maximum transmission unit 1916Byte, 1536Byte Configurable
8 Bandwidth management N × 32Kb/s ‘N’ is configurable
9 Fiber interface inside loopback Start, finish Configurable
10 Fiber interface outside loopback Start, finish Configurable
11 Loopback parameter
Exchange MAC address,
non-exchange MAC addres
s
Configurable
12
Fiber interface to copper interface fault
propagation
Enable, disable Configurable
13
Copper interface to fiber interface fault
propagation
Enable, disable Configurable
14 Fiber interface ALS Enable, disable Configurable
15 Copper interface: link status Up, down Uncontrollable, non-configurable
17 Copper interface: auto-negotiable Enable, manual Configurable
18 Copper interface: control Enable, disable Configurable
19 Copper interface: duplex mode Full duplex, half duplex Configurable
20 Copper interface: speed 10M, 100M Configurable
21 Fiber interface: transmit link Up, Down Uncontrollable, non-configurable
22 Fiber interface: receive link Up, Down Uncontrollable, non-configurable
23 Fiber interface: signal Normal, abnormal Uncontrollable, non-configurable
Note: all configurable items of SLAVE module can only be set through MASTER module; only SLAVE module status can
be reviewed locally.
6.2 Configure the Module
In the above table, all configurable items can be set through ‘config module’ command in NMS. These items include copper
