4.4Frontbezel
Attachingthefrontbezel
Beforettingthebezelyoumusthavemountedtheunitinits
requiredlocation.
1.Carefullyliftoneedgeofthescreenprotectionlm,sothatitis
accessibleforremovingwhenunitinstallationiscomplete.
2.PlacethebezeloverthefrontoftheC-SeriesDisplay,ensuring
thatlockinglugslocatedatthebottomedgeofthebezelare
latchedintoposition.
D11196-1
Clip recess
3.Ensurethatthecontrolbuttonspassthroughtheirrespective
openings.
4.Applyrmbutevenpressuretothebezelalongthe:
i.Outeredges-workfromthesidesupwardsandthenalong
thetopedge,toensurethatitclipssecurelyintoposition.
ii.Inneredges-particularlyalongthechartcarddooredge,to
ensurethatthebezelsitsat.
