5.4Sonarcheck

Warning:Sonaroperation

•NEVERoperatethesounderwiththeboatoutof

thewater.

•NEVERtouchthetransducerfacewhenthesounder

ispoweredon.

•SWITCHOFFthesounderifdiversarelikelytobe

within25ft(5m)ofthetransducer.

Selecttheshndertransducer

Youmustsetthesetupthesystemforthetransducerconnectedto

yourDSM.Usetheshndersetupmenustoselecttheappropriate

transducer.

Selectingtheshndertransducer

Fromthemainshnderscreen:

1.PresstheMENUbutton.

2.SelectFishnderSetupfromthelistofoptions.

3.SelectTransducerSettingsfromthelistofmenuoptions:

4.UsetheSelectTransduceroptionandselecttheappropriate

transducerfromthoseavailable.

Checkingthesonar

Sonarchecksaremadeusingtheshnderapplication.

1.PressthePAGEbuttontoshowtheavailablepagesinthe

toolbar.

2.PressthePAGEbuttontoswitchbetweentheavailablepages.

3.PressOKwhentheshnderisdisplayed.

4.Checktheshnderscreen.

Withtheshnderactiveyoushouldsee:

•Depthreading(indicatesthetransducerisworking).The

depthisshowninlargewhitenumbersatthebottomleftof

thescreen.

56C-SeriesWidescreeninstallation
