PinSignal
1Tx+
2Tx-
3Rx+
4Notconnected
5
Notconnected
6Rx-
7
Notconnected
8Notconnected
Note:UseonlyRaymarinecableswhenconnectingtoSeaTalk
hs
AppendixBNMEA0183sentences
TheC-SeriesWidescreendisplaysupportsthefollowingNMEA
0183sentences.TheseareapplicabletoNMEA0183andSeaTalk
protocols.
Transmit
APBAutopilotb
BWCBearinganddistancetowaypoint
BWR
Bearinganddistancetowaypoint
rhumbline
DBTDepthbelowtransducer
DPTDepth
MTWWatertemperature
RMB
Recommendedminimumnavigation
information
RSDRadarsystemdata
TTMTrackedtargetmessage
VHWWaterspeedandheading
VLWDistancetravelledthroughthewater
GGAGlobalpositioningsystemxdata
GLLGeographicpositionlatitudelongitude
GSAGPSDOPandactivesatellites
GSVGPSsatellitesinview
RMA
Recommendedminimumspecic
lorancdata
NMEA0183sentences85
