Instrument Specification
35
Instrument Specification
Supply voltage: 10 V to 16 V dc.
Current consumption (12 V supply): 35 mA typical.
70 mA with maximum backlighting.
Operating temperature: 0°C to +70°C.
Interfaces: SeaTalk.
Overall dimensions: 126 mm x 70 mm x 38 mm
(5.00 inches x 2.80 inches x 1.55 inches).
Boss diameter: 55 mm (2.20 inches).
Speed range: 0 to 99.9 knots.
Log range: 0 to 99999.
Trip reading range: 0 to 999 nautical miles.
Temperature reading range: -10°C to +40°C.
Depth range: 0 to 400 feet.
Shallow depth alarm: 0 to 29 feet.
Deep depth alarm: 30 to 400 feet.
Shallow anchor alarm: 1 to 250 feet.
Deep anchor alarm: 10 to 400 feet.
Approvals:
CE - conforms to
89/336/EC(EMC), EN60945.
94/25/EC(RCD), EN28846 (applies to
transducer only).
