Component Connections
33
Computers and Other Equipment with Audio/Video Outputs
Your TV can also be used as a display device for many video
games and home computers. If your game or computer has a
normal NTSC (American Standard) VIDEO output, it can be
connected directly to either the INPUT 1 or INPUT 2 jacks on
the TV as shown here.
If the computer or other device has monaural audio output (only
one AUDIO OUT jack instead of L and R), connect it to the
TV’s R/MONO jack. This will enable the TV to reproduce the
sound through both the left and right speakers.
To View Signals From Computer
• If you connected the computer to the TV’s INPUT 1 jacks,
select channel 91 on the TV so you can see whatever signal is
coming from the computer.
• If you connected the computer to the TV’s INPUT 2 jacks,
select channel 92 on the TV so you can see whatever signal is
coming from the computer.
