FITTING A RADIO
1
2
Radio location 1
If your vehicle is not fitted with an audio
system, one can be fitted and locations
have been provided for:
– the radio 1;
– front speakers 2;
– rear speakers 3.
To install any equipment, please con-
sult an approved dealer.
Unclip and remove storage compart-
ment 1.
Location for front speaker 2
Unclip cover 2 using a flat-blade screw-
driver or similar.
Location for rear speaker 3
Unclip cover 3 using a flat-blade screw-
driver or similar.
– In all cases, it is very important to follow the manufacturer’s instructions care-
fully.
– The specifications of the brackets and wires (available from our network) vary
depending on the equipment level of your vehicle and the type of radio.
Consult an approved dealer to find out the correct part number.
– No work may be carried out on the vehicle’s electrical or radio circuits, except
by approved Dealers: an incorrectly connected system may result in damage
being caused to the electrical equipment and/or the components connected to
it.
