air vents ................................................(up to the end of the DU)
heating system .....................................(up to the end of the DU)
heating and air conditioning system .....(up to the end of the DU)
AIR VENTS, air outlets (1/2)
6 Right-hand side window demister
vent
7 Right-hand side air vent
8 Front passenger footwell heater
outlets
9 Rear passenger footwell heater
outlets (depending on the vehicle)
1 Left-hand side air vent
2 Left-hand side window demister
vent
3 Windscreen demisting vents
4 Centre air vents
5 Control panel
4
5
1 2 3 76
88
9
9
