Renesas E2 Lite User Manual

E2 Lite Outline
R20UT3240EJ0300 Rev.3.00 Page 14 of 36
May.15.20
1.5 Regulatory Compliance Notices
1.5.1 European Union regulatory notices
This product complies with the following EU Directives. (These directives are only valid in the European
Union.)
CE Certifications:
• Electromagnetic Compatibility (EMC) Directive 2014/30/EU
EN 55032 Class A
WARNING:
This is a Class A product. This equipment can cause radio frequency noise when used in the
residential area. In such cases, the user/operator of the equipment may be required to take
appropriate countermeasures under his responsibility.
EN 55024
• Information for traceability
• Authorized representative & Manufacturer
Name: Renesas Electronics Corporation
Address: TOYOSU FORESIA, 3-2-24, Toyosu, Koto-ku, Tokyo 135-0061, Japan
• Person responsible for placing on the market
Name: Renesas Electronics Europe GmbH
Address: Arcadiastrasse 10, 40472 Dusseldorf, Germany
• Trademark and Type name
Trademark: Renesas
Product name: E2 Lite
Type name: RTE0T0002LKCE00000R
Environmental Compliance and Certifications:
• Waste Electrical and Electronic Equipment (WEEE) Directive 2012/19/EU
1.5.2 United States regulatory notices
This product complies with the following EMC regulation. (This is only valid in the United States.)
FCC Certifications:
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
CAUTION:
Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.

Renesas E2 Lite Specifications

General

On-Chip Debugging	Yes
Programming	Yes
Interface	USB
Operating System Support	Windows
Manufacturer	Renesas
Target Devices	Renesas MCUs
Supported Interfaces	JTAG
Debugging Features	Breakpoints
Software Compatibility	Renesas E2 Studio

Summary

1. Outline

1.1 Package Components

Lists the items included in the E2 Lite package.

1.2 System Configuration

Illustrates the connection between the E2 Lite, host machine, and user system.

1.3 PC Interface

Details the USB interface specifications for connecting to the host machine.

1.4 Specifications

Provides technical details including dimensions, weight, operating temperature, and EMC standards.

1.5 Regulatory Compliance Notices

Outlines EU and US regulatory compliance information and certifications.

1.6 E2 Lite Hardware Configuration

Shows the hardware layout of the E2 Lite main unit and its interface cables.

1.7 Names of the Emulator Parts

Identifies and describes the various parts, LEDs, and connectors on the E2 Lite.

1.8 Operating Environment

Specifies recommended conditions for temperature, humidity, and vibration during operation and storage.

2. Setup

2.1 Installing Emulator Software

Instructions for downloading and installing essential software for the E2 Lite.

2.2 Connecting the E2 Lite to the Host Machine

Step-by-step guide for connecting the E2 Lite to the host computer using a USB cable.

2.3 Connecting the E2 Lite to the User System

Procedure for connecting the E2 Lite to the target MCU on the user system.

2.4 Turning the Power On/Off

Details the correct sequence for powering the E2 Lite and user system on and off.

2.5 Connecting System Ground

Explains how to properly connect system ground to prevent damage and ensure safety.

2.6 Hot plug-in

Information on the optional hot-plug adapter for connecting the E2 Lite to a running user system.

3. Troubleshooting (Action in Case of an Error)

3.1 How to Solve a Trouble

Provides solutions for common issues encountered before the emulator debugger starts.

3.2 How to Request Support

Details how to contact technical support and what information to provide.

4. Maintenance and Warranty

4.1 Maintenance

Basic guidelines for cleaning and long-term storage of the E2 Lite.

4.2 Warranty

Information regarding product warranty, lack of repair services, and initial failure replacement.

Appendix A E2 Lite Self-Checking Program (SCP)

A.1 Flow of Self-Checking

Outlines the sequential steps for executing the E2 Lite self-checking program.

A.2 Preparations for Self-Checking

Lists the necessary hardware and software requirements for running the SCP.

A.3 Executing the SCP

Provides detailed instructions and visual examples for running the E2 Lite Self-Checking Program.
