Renesas E2 Lite User Manual

E2 Lite Setup
R20UT3240EJ0300 Rev.3.00 Page 24 of 36
May.15.20
2.4.2 When Power is Supplied to the User System from the Emulator
<When using the emulator>
(1) Connect the user system.
Follow the instructions in "2.3 Connecting the E2 Lite to the User System" to connect the emulator and
the user system with a user-system interface cable.
(2) Connect the host machine and turn on the emulator.
Follow the instructions in "2.2 Connecting the E2 Lite to the Host Machine" to connect the emulator and
the user system with a user-system interface cable, then turn on the emulator.
(3) Launch the emulator debugger or programming software and select the setting of power supply to the
user system.
(4) Connect the emulator debugger or programming software to the E2 Lite.
Connections may differ with the software.
<When finished using the emulator>
(1) Disconnect the E2 Lite from the emulator debugger or programming software.
Disconnections may differ with the software.
(2) Close the emulator debugger or programming software.
(3) Turn off and disconnect the emulator.
Disconnect the USB interface cable from the emulator, then turn off the emulator.
(4) Disconnect the user-system interface cable from the user system.
