Reolink RLN8-410 User Manual

Reolink PoE NVR
User Manual
7
You can set to require a password when unlock the screen to protect the NVR
system. Or you can set the NVR to automatically lock the screen and then requires
a password to unlock. It can be set up at NVR Settings > System > General page.
Camera Settings
Stream
Go to Settings > Camera > Stream, here you can change the resolution, frame rate
and bit rate of the camera. Set up a higher resolution provides a better image
quality, but also requires a much higher network bandwidth and uses up more
storage space while recording.
Display
Go to Settings > Camera > Display, here you can set up the Camera Name, Time
Stamp, Watermark, Flip and Mirror etc.
Disable Preview: Turn on or off live view of the camera.
Camera Name: Set a name for the camera.
Time Stamp: Set the position of the Time Stamp, you can choose from Top Left,
Top Right, Bottom Left, and Bottom Right.
Watermark: Turn on or off the Reolink Logo on the live view.
Flip Display: Turn the camera’s image upside down when enable this option.

Reolink RLN8-410 Specifications

General

Video codecs	H.264
Display modes	Live view
Number of users	20 user(s)
Maximum resolution	3840 x 2160 pixels
Video input channels	8 channels
Supported resolutions	3840x2160, 1920x1080, 1440x900, 1280x1024, 1280x800, 1280x720, 1024x768
On/off switch	Yes
Product color	Black
Audio RCA outputs	1
Networking standards	IEEE 802.3af, IEEE 802.3at
USB 2.0 ports quantity	2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	9
Supported network protocols	HTTP, TCP/IP, UDP, DHCP, P2P, UPNP, RTSP, SMTP, SSL/TLS, DNS, DDNS, NTP, FTP
Power over Ethernet (PoE) ports quantity	8
Wi-Fi	No
HDD capacity	2000 GB
HDD interface	SATA, SATA II, SATA III
Maximum storage capacity	8 TB
Output current	2 A
Output voltage	48 V
Power consumption (max)	25 W
Operating temperature (T-T)	-10 - 45 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	230 mm
Width	260 mm
Height	41 mm
Weight	1200 g
