Rheem 862 27 Series User Manual

TM049 27L Continuous Flow Service Instructions
REV AL – Issued April 2019
This document is stored and maintained electronically by Rheem Technical Support. All printed copies are deemed “uncontrolled”.
26
Bath Fill Operation
Bath Fill Operation
Deluxe controllers only
B
Bath fill lamp on
Hot water volume indicator on
Hot water volume on
Hot water temperature
indicator on
Bath fill switch on
Hot water tap open
YES
Bath fill lamp off
Hot water volume indicator off
Hot water volume off
Bath fill operation
completed
Hot water temperature
indicator off
NO
Combustion A - B
NO
YES
Burner Off
NO
YES
Bath fill lamp flashing
Hot water volume indicator off
Hot water volume off
Hot water temperature
indicator off
Water flow control valve
closed
65 Flashing
8.5 seconds later
Hot water tap closed
YES
Bath fill lamp off
Water flow control valve
open
NO
YES
Bath fill switch on less
than 6 hours?
Bath fill switch off?
Water delivered less
than or equal to set
volume?
Water flow sensor off? NO
Bath fill switch off?
