IKONIC Tankless Water Heater Service Manual
66
3.3 FLAME ROD
HOW TO REMOVE COMPONENTS
1. Remove the hook film part of the Over Heat Limiter
(OHL ). DO NOT cut the film.
2. Remove flame rod wire from the rod.
3. Remove 3 screws from flame rod bracket, and pull
the flame rod.
NOTE: When reassembling flame rod, please
use a spare gasket if the condition of the gas-
ket is not good.
The spare gasket is located at lower left in
the unit.
Flame Rod
Igniter Rod
