11.0 SEQUENCE OF OPERATION
11.1 COOLING (COOLING ONLY OR HEAT PUMP)
• When the thermostat “calls for cooling,” the circuit between R and G is completed,
causing the blower relay (BR) to energize. The N.O. contacts will close, causing the
indoor blower motor (IBM) to operate. The circuit between R and Y is also completed:
This circuit closes the contactor (CC) in the outdoor unit starting the compressor
(COMP) and outdoor fan motor (OFM).
11.2 HEATING (ELECTRIC HEAT ONLY)
• When the thermostat “calls for heat,” the circuit between R and W is completed, and
the heater sequencer (HR
1) is energized. The heating elements (HE) and the indoor
blower motor (IBM) will come on. Units with a second heater sequencer (HR
2) can be
connected with the first sequencer (HR
1) to W on the thermostat sub-base or con-
nected to a second stage W
2 on the sub-base.
11.3 HEATING (HEAT PUMP)
• When the thermostat “calls for heat,” the circuits between R and B, R and Y and R
and G are completed. Circuit R and B energizes the reversing valve (RV) switching it
to the heating position (remains energized as long as selector switch is in “heat” posi-
tion). Circuit R and Y energizes the contactor (CC) starting the outdoor fan motor
(OFM) and compressor (COMP). Circuit R and G energizes the blower relay (BR)
starting the indoor blower motor (IBM).
!"#$#%&'()*(+,(-%.(,/%&012-,(-%&012/
OD DB
13PJP18
RHBL-FR24T
13PJP24
RHBL-FR24T
13PJP30
RHBL-FR36T
13PJP36
RHBL-FR36T
&''3,(-%4')*%5%#2*++62*%7*86,2*9*(/+%5%:2'++%&012-*%&0*;<%=>?@%A?,86,)%#2*++62*%B%C1D'2%#2*++62*E
115
525 / 154 553 / 151 511 / 149 488 / 143
105
460 / 152 487 / 149 452 / 147 430 / 140
95 399 / 150 428 / 146 398 / 145 378 / 139
82 333 / 146 358 / 143 333 / 142 316 / 136
75 302 / 144 322 / 141 302 / 140 286 / 133
55 221 / 141 238 / 136 224 / 136 212 / 129
&''3,(-%4')*%5%F6G5&''3,(-%7*86,2*9*(/+%5%H,(13%&012-*%C*2,I,;1/,'(
115
21 22 14 11
105
20 21 14 11
95 19 20 14 11
82 18 20 14 11
75 19 20 13 11
55 18 19 13 12
J*1/,(-%4')*%5%#2*++62*%7*86,2*9*(/+%5%:2'++%&012-*%&0*;<%=>?@%A?,86,)%#2*++62*%B%C1D'2%#2*++62*E
60
356 / 121 350 / 103 338 / 107 372 / 111
47 318 / 104 321 / 92 324 / 97 342 / 98
35 273 / 84 262 / 78 294 / 84 291 / 82
17 255 / 61 255 / 55 265 / 59 272 / 58
J*1/,(-%4')*%5%F6G5&''3,(-%7*86,2*9*(/+%5%H,(13%&012-*%C*2,I,;1/,'(
60 19 18 24 29
47 16 17 23 27
35 10 12 18 21
17 7 6 11 14
