Ricoh Aficio MP 2851 User Manual

Installing the Printer Driver Using USB
This section explains how to install printer drivers using USB.
Before installing, check that only the operating system is running on the computer and no print jobs are in
progress.
You can use the printer driver included on the CD-ROM provided with this machine, or can download it
from the supplier's web site.
Windows 2000 - USB
• To install a printer driver, you must have Administrator privilege. Log on using an account that has
Administrator privilege.
When USB is first used, Found New Hardware Wizard starts, and USB Printing Support is installed
automatically.
If the printer driver is already installed and plug-and-play is enabled, the icon of the printer connected to
the "USB" port appears in the [Printers] window.
The printer drivers can be installed from the CD-ROM provided with this machine.
If the printer driver is not already installed, follow the printer's plug-and-play instructions to install it from
the provided CD-ROM.
1. Check that the power of the machine is off.
2. Connect the machine to the computer using a USB cable.
Connect the USB cable firmly.
3. Turn on the power of the machine.
Found New Hardware Wizard starts, and USB Printing Support is installed automatically.
4. In the Found New Hardware Wizard window, click [Search for a suitable driver for my
device [recommended]], and then click [Next >].
5. Select the [Specify location] check box, and then click [Next >].
6. Insert the CD-ROM into the CD-ROM drive.
If Auto Run starts, click [Cancel] and then [Exit].
7. Specify the location where the source files of the printer driver are stored.
If the CD-ROM drive is D, the source files of the printer driver are stored in the following location:
• PCL 5e
D: DRIVERS PCL5E XP_VISTA (Language) DISK1
• PCL 6
1. Preparing the Machine
48
1

Ricoh Aficio MP 2851 Specifications

General

Print Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Scan Resolution	600 dpi
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Print Technology	Laser
First Print Speed	4.5 seconds
Interface	USB 2.0, Ethernet
Max Paper Size	A3
Print Speed	28 ppm
Paper Capacity	1, 600 sheets max
Network Connectivity	Ethernet 10/100Base-TX
Warm-up Time	Less than 20 seconds
Copy Speed	28 cpm
Zoom	25% - 400%
Multiple Copy	Up to 999 copies
Paper Size	A3, A4, A5, B4, B5, A6
Memory	768 MB
PDL	PCL6, RPCS
Operating System Compatibility	Windows, Mac
Fax Transmission Speed	3 seconds
