Ricoh Aficio MP171 User Manual

Problems Intervals Defective parts
Problems with the printed result
(other than black or white dots)
29.9mm Charge roller
37.7mm Registration roller
45.8mm Image transfer roller
112mm Fusing pressure roller
94mm Fusing roller
100.5mm Paper feed roller
Black or white dots
35.6mm Development roller
94.4mm Drum
The LED head contains 26 LED chips, each covering a line 8 mm wide. If a line 8 mm wide extending in
the paper feed direction appears, an LED chip may be damaged. If so, replace the LED head.
Troubleshooting
153

Ricoh Aficio MP171 Specifications

General

Resolution	600 x 600 dpi
Maximum Paper Size	A3
Paper Capacity	250 sheets
Max Paper Capacity	1, 350 sheets
Printing Technology	Laser
Power Source	220 - 240V, 50/60Hz
Copy Speed	17 ppm
Multiple Copy	Up to 99
Zoom Range	50% to 200%
