Ricoh Aficio SP C242SF User Manual

Configuring the IPv4 Address Settings
The machine is set to obtain IPv4 address information automatically by the network by default (DHCP). If
you want to assign IPv4 address information manually, follow the procedure below.
• If you are using the machine on a network that uses DHCP, print the configuration page to check
the IPv4 address information assigned to the machine. Perform steps 15 to 18 of the procedure
below.
1. Press the [User Tools] key.
2. Press the [ ] [ ] keys to select [Network Settings], and then press the [OK] key.
3. If you are requested to enter a password, enter the password using the number keys,
and then press the [OK] key.
4. Press the [ ] [ ] keys to select [IPv4 Configuration], and then press the [OK] key.
5. Press the [ ] [ ] keys to select [DHCP], and then press the [OK] key.
6. Press the [ ] [ ] keys to select [Inactive], and then press the [OK] key.
7. Press the [ ] [ ] keys to select [IP Address], and then press the [OK] key.
The current IPv4 address is shown.
8. Enter the machine’s IPv4 address using the number keys, and then press the [OK] key.
Press the [ ] [ ] keys to move between fields.
9. Press the [ ] [ ] keys to select [Subnet Mask], and then press the [OK] key.
The current subnet mask is shown.
10. Enter the subnet mask using the number keys, and then press the [OK] key.
Press the [ ] [ ] keys to move between fields.
11. Press the [ ] [ ] keys to select [Gateway Address], and then press the [OK] key.
The current gateway address is shown.
12. Enter the gateway address using the number keys, and then press the [OK] key.
Press the [ ] [ ] keys to move between fields.
13. Press the [User Tools] key to return to the initial screen.
14. If you are requested to restart the machine, turn off the machine, and then turn it back on.
15. Press the [User Tools] key.
16. Press the [ ][ ] keys to select [Print List/Report], and then press the [OK] key.
17. Press the [ ][ ] keys to select [Configuration Page], and then press the [OK] key.
Configuring the IPv4 Address Settings
9
1

Ricoh Aficio SP C242SF Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Digital sender	-
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	4
Page description languages	PCL 5c, PCL 6, PostScript 3
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	20 cpm
Scan to	E-mail, File
Scan drivers	TWAIN, WIA
Maximum scan area	216 x 356 mm
Image formats supported	JPG, TIF
Document formats supported	PDF
Optical scanning resolution	1200 x 1200 DPI
Fax memory	100 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	200 x 200 DPI
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	751 sheets
Multi-Purpose tray input capacity	1 sheets
Auto document feeder (ADF) input capacity	35 sheets
Maximum print size	210 x 297 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 160 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Product color	Grey, White
Market positioning	Business
Standard interfaces	Ethernet, USB 1.1, USB 2.0
USB 2.0 ports quantity	1
Fax compatibility	ITU-T G3
Networking features	Fast Ethernet
Supported network protocols	TCP/IP (IPv4, IPv6), IPP, Bonjour
Internal memory	256 MB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1300 W
Power consumption (PowerSave)	10 W
Power consumption (average operating)	- W
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
Server operating systems supported	Windows Server 2003 R2, Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Bundled software	PageManager\\r PC Fax Utility
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	493 mm
Width	420 mm
Height	476 mm
Weight	30000 g
